参数 型号 |
额定处理气量 (m3/min) |
额定工作压力 (Mpa) |
接口尺寸 |
重量 (kg) |
JG-0.5/14 | 0.5 | 1.4 | G1/2” | 4.1 |
JG-1.0/14 | 1.0 | 1.4 | G1/2” | 4.2 |
JG-1.6-14 | 1.6 | 1.4 | G3/4” | 4.5 |
JG-2.0/14 | 2.0 | 1.4 | G3/4” | 4.8 |
JG-2.5/14 | 2.5 | 1.4 | G1” | 5.6 |
JG-3.0/14 | 3.0 | 1.4 | G1” | 5.7 |
JG-4.0/14 | 4.0 | 1.4 | G1” | 6.2 |
JG-6.0/14 | 6.0 | 1.4 | G2” | 9.8 |
JG-8.0/14 | 8.0 | 1.4 | G2” | 10.4 |
JG-10/14 | 10 | 1.4 | G2” | 10.8 |
JG-15/14 | 15 | 1.4 | DN80 | 49 |
JG-20/14 | 20 | 1.4 | DN80 | 52 |
JG-25/14 | 25 | 1.4 | DN80 | 74 |
JG-30/14 | 30 | 1.4 | DN100 | 80 |
JG-40/14 | 40 | 1.4 | DN100 | 102 |
JG-50/14 | 50 | 1.4 | DN100 | 104 |
JG-60/14 | 60 | 1.4 | DN150 | 108 |
JG-80/14 | 80 | 1.4 | DN150 | 145 |
JG-100/14 | 100 | 1.4 | DN200 | 152 |
GCF-1.0/40 | 1.0 | 4.0 | 30×1.5 | 5.1 |
GCF-1.6/40 | 1.6 | 4.0 | 30×1.5 | 5.3 |
GCF-2.0/40 | 2.0 | 4.0 | 30×1.5 | 5.5 |
GCF-2.5/40 | 2.5 | 4.0 | 30×1.5 | 5.5 |
GCF-3.0/40 | 3.0 | 4.0 | 36×2 | 6.2 |
GCF-4.0/40 | 4.0 | 4.0 | 36×2 | 6.8 |
GCF-6.0/40 | 6.0 | 4.0 | 36×2 | 7.5 |
GCF-8.0/40 | 8.0 | 4.0 | 36×2 | 9.8 |
GCF-10.0/40 | 10.0 | 4.0 | 36×2 | 10.5 |
